The Linear Servo Motor used on a vertical axis will require a counterbalance to offset gravity. Without a counterbalance the motor will fall when it is de-energized. gLESS is a counterbalance mechanism which utilizes a magnetic force to offset gravitational ...

The shaft motor that makes up the Z-axis is equipped with a gLESS counterbalance and four Aicams Labs pipettes. The icomes pipette is thin (9 mm) and light (less than 200 g), The pipette is equipped with a unique Φ8mm ...

The 10-axis demo provides a glimpse into the power of the linear shaft motor and the Commander series controller in providing a coordinated dance of speed and precision. Precision, speed, simplicity of design, and space savings are all on display ...

Our wafer transfer mechanism illustrates 6 axes of motion under the power of our Micro Direct Drive motors. Starting with the transfer mechanism itself, the see-thru construction provides a glimpse at the muscles underneath the enclosure. The base motor is ...

Our 3-axis gantry demo is an example of the capabilities of a simple XYZ solution for various applications such as ultrasonic inspection, dispensing, or pick and place, etc. The 3-axis gantry demo consists of 3 SLP15 linear shaft motor stages ...

Nippon Pulse 4-axis COMMANDER controller is a hybrid IC that bridges the gap between design-from-scratch and off-the-shelf motion controllers. COMMANDER is secure, flexible and easy to use.

The Linear Servo Motor outperforms competing linear motors when high speed and high precision are needed simultaneously. The Linear Servo Motor is able to achieve sub-micron resolutions, and also greatly decreases the impact of heat on the workpoint.

Nippon Pulse's Linear Servo Motor is the first linear servomotor designed for the ultra-high-precision market. Its design features greater stiffness, no cogging, a non-critical air gap, and less heat generation, which allow the Linear Servo Motor to achieve sub-micron resolution.

The Linear Servo Motor is built for the ultra high-precision market, but is also designed to handle lower-resolution applications. The Linear Servo Motor is more efficient and produces less heat than other linear motors, such as platen-style and U-shaped systems.

Our Linear Servo Motor can be used in a variety of vertical applications. A vertical alignment of the Linear Servo Motor can be seen here, as can a variety of motion profiles. This is a S160T motor. View all of ...

This pick-and-place machine utilizes both a Linear Servo Motor and one of Nippon Pulse's rotary tin-can stepper motors. The stepper rotates at the point of the pick-and-place, while the Linear Servo Motor moves the machine's arm along the X-axis.

With a travel distance of 2 m/s and an acceleration of 2G, four Linear Servo Motors run in parallel off of just one encoder and one servo drive.
